Model |
SSH-600S |
SSH-700S |
SSH-800S |
||
Cutting line |
one line |
||||
Bag width |
500mm |
600mm |
700mm |
||
Bag length |
1000mm |
||||
Cutting speed |
50-120pcs/min |
||||
Motor |
Stepping motor |
||||
Main motor |
1.5KW |
||||
Heating capacity |
2.5KW |
||||
Air pressure |
0.5-06Mpa |
||||
Air cylinder used |
One Piece |
||||
Power supply |
220V, 50Hz |
||||
Electronics used |
Top China Brand |
||||
Machine weight |
1500kg |
1600kg |
1700kg |
||
Installed dimension |
5×1.15×1.8M |
5×1.25×1.8M |
5×1.35×1.8M |
||
Optional device |
(two lines) Servo motor, imported photocell |
