Model |
SJCOT-55 |
SJCOT-60 |
SJCOT-65 |
|||||||||||||
Features |
Raw Material |
HDPE, LDPE, LLDPE; Virgin and Recycled |
||||||||||||||
Film Width |
800mm |
1500mm |
2000mm |
|||||||||||||
Output |
80Kgs |
120Kgs |
150Kgs |
|||||||||||||
Film Thickness |
0.008mm-0.15mm |
|||||||||||||||
Power supply |
380V, 3Phase, 50Hz |
|||||||||||||||
Weight |
3000kg |
3500kg |
4000kg |
|||||||||||||
Dimension |
6×5×5.5M |
6×6×7M |
6×7×7.5M |
|||||||||||||
Extrusion Unit |
Screw&Barrel Diameter |
50mm*2 55mm*1 |
55mm*2 60mm*1 |
60mm*2 65mm*1 |
||||||||||||
Screw&Barrel L/D ratio |
32:1 |
|||||||||||||||
Motor Power |
15kw*2 22kw*1 |
18.5kw*2 30kw*1 |
30kw*2 45kw*1 |
|||||||||||||
Gearbox |
146/173 |
146/173 |
173 |
|||||||||||||
Die Head Type |
Rotary Die Head |
|||||||||||||||
Die Size |
250/200mm |
350/300mm |
5560mm |
|||||||||||||
Heating |
50KW |
60KW |
80KW |
|||||||||||||
Blower |
7.5KW |
|||||||||||||||
Film Taking-up Tower |
Upper Tower Type |
Rise and Fall |
||||||||||||||
Roller Length |
1000mm |
1700mm |
2200mm |
|||||||||||||
Roller Working Way |
Opened and Tightened By Air Cylinders |
|||||||||||||||
Take Up Motor |
1.5KW |
|||||||||||||||
Winding Station |
Winder Type |
Single winding station |
||||||||||||||
Rollers Length |
700mm |
700mm |
900mm |
|||||||||||||
Torque Motor |
5N/M |
|||||||||||||||
Max. Winding Diameter |
600mm |
|||||||||||||||
Control Panel |
Temperature control |
5 zone |
||||||||||||||
Electronics |
Top China Brand |
|||||||||||||||
Inverter Capacity |
11KW/1.5KW |
11KW/1.5KW |
15KW/1.5KW |
|||||||||||||
Optional Equipment |
Hopper loader, Corona, Mechanical screen changer |
